Monolithic Insulation Joints and Pipeline Isolation Fittings for Energy Infrastructure

NUPROS manufactures NUSEAL insulation joints for EPC and CP contractors in petroleum, gas, and water pipeline systems across the Middle East and Asia.

Contact usProducts and Pipeline Components
NUSEAL Monolithic Insulation Joint
Insulating Flange Assembly
Insulating Gasket Kit
1,500 m² total factory area; 850 m² workshop; equipment includes 750-ton hydraulic press, multiple TIG/MIG/ARC welding sets, and 5-ton EOT cranesIndia
25+
Years in operation
1,500 m²
Factory area
India, Saudi Arabia, Kuwait, United Arab Emirates
Export markets
ISO 9001:2015, ISO 14001:2015, ISO 45001:2018, EN 10204 3.1/3.2, NABL Approved Lab
Certifications
1,500 m² total factory area; 850 m² workshop; equipment includes 750-ton hydraulic press, multiple TIG/MIG/ARC welding sets, and 5-ton EOT cranesIndiaSaudi ArabiaKuwaitUnited Arab Emirates
ISO 9001:2015ISO 14001:2015ISO 45001:2018EN 10204 (3.1 / 3.2 material certification)NABL Approved Lab (for physical/chemical/micro/hardness testing)

Supplier-declared, pending confirmation

Products and Pipeline Components

NUSEAL Monolithic Insulation Joint

NUSEAL Monolithic Insulation Joint

Pipe sizes 1/2" to 100"+, ANSI 150 to ANSI 2500 and API 10000+; butt welded, WNRF, RF, or RTJ end connections; NEMA G10/G11 thermosetting epoxy composite insulation; internal and external coating exceeding 150 microns.

Size Range
1/2" up to 100" and over
Pressure Rating
ANSI 150 to ANSI 2500, API 10000 and over
End Connections
Butt welded, WNRF, RF, RTJ, or per client specification
Certification Standard
EN 10204 3.1 or 3.2
NDT - PUP Bevels
100% MT/UT/ASME V - ASME VIII
NDT - W3 Closure Weld
100% MT/UT/ASME V - ASME VIII

Insulating Flange Assembly

Full flange isolation kit configured to client pressure class and pipe schedule for cathodic protection continuity break.

Insulating Gasket Kit

Dielectric gasket sets supplied to ANSI flange dimensions for electrical isolation in petrochemical and water systems.

AGA 3 / AGA 9 Finished Metering Spool

Fabricated metering spool assemblies built to AGA 3 (orifice) or AGA 9 (ultrasonic) standards for custody-transfer gas measurement.

Flow Measurement and Conditioning

Flow profilers and flow straighteners engineered to reduce upstream disturbance and improve meter accuracy in gas and liquid pipeline systems.

  • Flow Profiler
  • Flow Straightener

Fabricated Pipe Spool and Accessories

Custom fabricated pipe spools, gauge hatches, and rain caps / vent flappers built to project drawings and applicable standards.

  • Fabricated Pipe Spool
  • Gauge Hatch
  • Rain Cap / Vent Flapper

Why Contractors Specify NUPROS

Full size and pressure range

NUSEAL joints are produced from 1/2" through 100"+ and rated from ANSI 150 to ANSI 2500 and API 10000+, covering virtually every onshore pipeline and station application without the need for a secondary supplier.

750-ton press, in-house fabrication

A 750-ton hydraulic press, multiple TIG/MIG/ARC welding sets, and 5-ton EOT cranes allow NUPROS to manufacture heavy-wall and large-bore components entirely in-house, reducing lead-time risk for EPC schedules.

NABL-accredited material testing

Physical, chemical, microstructural, and hardness testing is conducted in an NABL-approved laboratory on-site, supporting EN 10204 3.1 and 3.2 material certification with full traceability.

Integrated QHSE management system

Simultaneous certification to ISO 9001:2015, ISO 14001:2015, and ISO 45001:2018 reflects a single integrated management system, which simplifies contractor vendor qualification audits.

Configurable to client specifications

End connections (butt weld, WNRF, RF, RTJ), coating thickness, insulation material grade (NEMA G10/G11), and testing requirements are all configurable, so no standard product compromise is required.

Established in export supply since 1999

NUPROS has supplied EPC and cathodic protection contractors in Saudi Arabia, Kuwait, and the United Arab Emirates, building a documented export track record for projects where vendor history is a qualification criterion.

Sourcing FAQ

What pipe sizes and pressure classes are available for NUSEAL monolithic insulation joints?

NUSEAL joints are manufactured from 1/2" to 100"+ nominal pipe size. Pressure ratings cover ANSI Class 150 through ANSI Class 2500 and API 10000+. End connections available include butt weld, WNRF, raised face (RF), and ring-type joint (RTJ).

What insulation material is used, and what coating is applied?

Insulation is NEMA G10 or G11 thermosetting epoxy composite, selected based on service temperature and pressure class. Internal and external protective coatings are applied to a minimum thickness of 150 microns.

Is NUPROS a manufacturer or a trading company?

NUPROS PVT LTD is a manufacturer. Products are fabricated in-house at an 850 m² workshop equipped with a 750-ton hydraulic press and in-house welding and testing facilities.

Which material certifications and quality standards apply?

NUPROS holds ISO 9001:2015, ISO 14001:2015, and ISO 45001:2018. Material certification is issued to EN 10204 3.1 or 3.2 upon request. Testing is performed in an NABL-approved on-site laboratory covering physical, chemical, microstructural, and hardness analysis.

Which HS codes cover these products?

Monolithic insulation joints and gasket assemblies typically fall under HS 8484.10 (gaskets and similar joints) or HS 7307.99 (pipe fittings). Flow measurement spools may be classified under HS 9026.80. Buyers should confirm classification with their customs authority.

Which export markets does NUPROS currently serve, and can it supply to new geographies?

NUPROS currently exports to India, Saudi Arabia, Kuwait, and the United Arab Emirates. The company targets EPC and CP contractors across the Middle East, Southeast Asia, and Africa. Inquiries from other regions are welcome via the form below.

How do I request pricing or discuss a project requirement?

Use the pricing request form on this page. Provide your pipe size, pressure class, end connection type, quantity, and applicable project standard, and the NUPROS technical team will respond with pricing and a data sheet.
